Nikon AF-S DX NIKKOR 55-200mm f/4-5.6G ED VR
Compact telephoto zoom for DX-format Nikon DSLRs
Key Features
Lens Capabilities
Click the Links Below for Details
The Most Important Rings & Switches — Nikon AF-S DX NIKKOR 55-200mm f/4-5.6G ED VR
| Ring / Switch / Control | Status | Note |
|---|---|---|
| Focus Ring | ✓ Present | Manual focus ring located at the front |
| Zoom Ring | ✓ Present | Large rubberized ring for focal length adjustment |
| Aperture Ring | ✗ Not Present | Aperture controlled via camera body |
| AF/MF Switch | ✓ Present | Side switch for focus mode selection |
| Image Stabilisation Switch | ✓ Present | Switch to toggle VR on/off |
| Focus Limiter Switch | ✗ Not Present | |
| Function (L-Fn) Button | ✗ Not Present | |
| Zoom Lock Switch | ✗ Not Present | |
| Optical Image Stabilisation (OIS) | ✓ Present | Nikon VR system |
| Weather Sealing | ✗ Not Present | Not weather sealed |
How-to Use Nikon AF-S DX NIKKOR 55-200mm f/4-5.6G ED VR
Welcome to the How-to section of the lens. In this Light & Composition University website, each page for a lens has a how-to section and a section for learning. The rings, switches and controls of each lens are placed differently between brands and models. The how-to section helps you operate the lens; however, if you are interested in learning photography, you also need to know what each control changes and why you would change it. Click the “Learn” or scroll down.
Learn & Master Photography with Nikon AF-S DX NIKKOR 55-200mm f/4-5.6G ED VR
For over a decade, we have been teaching photography following a university standard. No one does it better than us. We have a selection of courses, diplomas, graduate and post-graduate programs, as well as some of our best-selling university press publications, to guide you in the best possible way for your lens. Enroll in the fundamentals and then move to the genres you want to master.
Technical Specification
| Focal Length | 55-200mm |
| Max Aperture | f/4-5.6 |
| Min Aperture | f/22-32 |
| Lens Construction | 15 elements in 11 groups |
| Angle of View | 28u00b050' - 8u00b0 |
| Min Focus Distance | 1.1m (3.7ft) |
| Max Reproduction Ratio | 0.23x |
| Diaphragm Blades | 7 (rounded) |
| Filter Size | 52mm |
| Focus Motor | Silent Wave Motor (SWM) |
| Stabilization | VR (Vibration Reduction) |
| Dimensions | 73 x 99.5 mm |
| Weight | 335g |
| Mount | Nikon F-mount |
| Format | DX (APS-C) |
