Sigma 24-70mm f/2.8 DG DN Art II
The ultimate professional standard zoom lens refined.
Key Features
Lens Capabilities
Click the Links Below for Details
The Most Important Rings & Switches — Sigma 24-70mm f/2.8 DG DN Art II
| Ring / Switch / Control | Status | Note |
|---|---|---|
| Focus Ring | ✓ Present | |
| Zoom Ring | ✓ Present | |
| Aperture Ring | ✓ Present | |
| AF/MF Switch | ✓ Present | |
| Image Stabilisation Switch | ✗ Not Present | |
| Focus Limiter Switch | ✗ Not Present | |
| Function (L-Fn) Button | ✓ Present | |
| Zoom Lock Switch | ✓ Present | |
| Optical Image Stabilisation (OIS) | ✗ Not Present | |
| Weather Sealing | ✓ Present |
How-to Use Sigma 24-70mm f/2.8 DG DN Art II
Welcome to the How-to section of the lens. In this Light & Composition University website, each page for a lens has a how-to section and a section for learning. The rings, switches and controls of each lens are placed differently between brands and models. The how-to section helps you operate the lens; however, if you are interested in learning photography, you also need to know what each control changes and why you would change it. Click the “Learn” or scroll down.
Learn & Master Photography with Sigma 24-70mm f/2.8 DG DN Art II
For over a decade, we have been teaching photography following a university standard. No one does it better than us. We have a selection of courses, diplomas, graduate and post-graduate programs, as well as some of our best-selling university press publications, to guide you in the best possible way for your lens. Enroll in the fundamentals and then move to the genres you want to master.
Technical Specification
| Lens Type | Standard Zoom |
| Focal Length | 24-70mm |
| Max Aperture | f/2.8 |
| Min Aperture | f/22 |
| Elements/Groups | 19 / 15 |
| Diaphragm Blades | 11 (Rounded) |
| Min Focus Distance | 17-34cm |
| Max Magnification | 1:2.7 (at 24mm) |
| Filter Thread | 82mm |
| Focus Motor | HLA Linear Motor |
| Weather Sealing | Yes |
| Weight | 735g (E-mount) |
| Dimensions | 87.8 x 120.2 mm |
