Sigma 60-600mm f/4.5-6.3 DG DN OS Sports
The ultimate 10x ultra-telephoto zoom lens
Key Features
Lens Capabilities
Click the Links Below for Details
The Most Important Rings & Switches — Sigma 60-600mm f/4.5-6.3 DG DN OS Sports
| Ring / Switch / Control | Status | Note |
|---|---|---|
| Focus Ring | ✓ Present | |
| Zoom Ring | ✓ Present | |
| Aperture Ring | ✗ Not Present | |
| AF/MF Switch | ✓ Present | |
| Image Stabilisation Switch | ✓ Present | |
| Focus Limiter Switch | ✓ Present | |
| Function (L-Fn) Button | ✓ Present | |
| Zoom Lock Switch | ✓ Present | |
| Optical Image Stabilisation (OIS) | ✓ Present | |
| Weather Sealing | ✓ Present |
How-to Use Sigma 60-600mm f/4.5-6.3 DG DN OS Sports
Welcome to the How-to section of the lens. In this Light & Composition University website, each page for a lens has a how-to section and a section for learning. The rings, switches and controls of each lens are placed differently between brands and models. The how-to section helps you operate the lens; however, if you are interested in learning photography, you also need to know what each control changes and why you would change it. Click the “Learn” or scroll down.
Learn & Master Photography with Sigma 60-600mm f/4.5-6.3 DG DN OS Sports
For over a decade, we have been teaching photography following a university standard. No one does it better than us. We have a selection of courses, diplomas, graduate and post-graduate programs, as well as some of our best-selling university press publications, to guide you in the best possible way for your lens. Enroll in the fundamentals and then move to the genres you want to master.
Technical Specification
| Focal Length | 60-600mm |
| Aperture Range | f/4.5-6.3 to f/22-32 |
| Lens Construction | 27 elements in 19 groups |
| Diaphragm Blades | 9 (rounded) |
| Minimum Focus Distance | 45-260cm |
| Maximum Magnification | 1:2.4 (at 200mm) |
| Filter Size | 105mm |
| Dimensions | 119.4 x 279.2 mm |
| Weight | 2495g |
| Mount | Sony E, Leica L |
| Stabilization | Optical OS (7 stops wide, 6 stops tele) |
| Focus Motor | HLA Linear Motor |
| Weather Sealing | Yes, dust and splash resistant |
| Tripod Collar | Included, Arca-Swiss compatible |
| Zoom Type | Rotary and Push-Pull |
